HD code stream coaxial monitoring and testing instrument, supporting ADH, TVI, CVI, CVBS video format supports up to 8MP high-definition video. It also has video display. RS485 PTZ control, DC12V power output, audio test, VGA/ video signal input, network cable test, video output, color strip output, LED night lighting and other functions Video signal test function. HD video monitoring tester, built-in high-definition 5.0 inch 800 (RGB) x 480. Wide angle display, supporting PAL/NTSC image signal. PTZ control function. The video monitoring tester is equipped with Pelco D/P and other PTZ control protocols. RS485 interface, which can control the top, bottom, left and right of the PTZ, zoom, focus and aperture DC12V 1A power output function. The video monitoring tester is specially designed with 12V 1A power supply for camera power supply The outlet port provides temporary power supply for the camera. Audio test function. The audio test function of the video monitoring tester can be used to test the pickup on the front end of the video monitoring. Wait for audio equipment to test Network cable test function, through the UTP CABLE TEST test port on the instrument, Can test the connection and disconnection of cable. Support VGA video input, resolution support 1024x768&1280x720&1280x1024&1440x900&1920x1080. Support video input, resolution support 1024x768&1280x720&1280x1024&1440x900&1920x1080 5-inch TFT LCD Screen 6 in 1 CCTV Tester PAL/NTSC ,Hybrid camera tester is to test and debug coaxial 720P / 960P / 1080P /3MP/4MP/5MP/8MP AHD camera & CVI camera & TVI camera and traditional CVBS analog camera (IP &SDI camerasare not supported) input, support 1024x768 &1280x720 & 1280x1024 & 1440x900 & 1920x1080 resolution . VGA input:support 1024 x 768 and 1280 x 1024 and 1440x900 and 1920x1080 resolutions . PTZ CONTROL:Support RS485,Compatible with multiple PTZ protocols (PELCO-D / PELCO-P ); baud rate: 1200,2400, 480
